Renewable connection
Solar farm grid connection
Connection studies, a new 33 kV feeder bay and protection settings for a ground-mount solar development — energised within the operator's agreed window.
Transmission · Distribution · Renewables
High-voltage
engineering,
zero guesswork.
EHV/HVVoltage classes
Grid codeCompliant by design
24/7Fault response
The system we build
From generator busbar
to consumer meter.
Voltline delivers the engineered chain between generation and demand — every link designed, tested and documented to the same standard.
One accountable partner across the whole chain means fewer interfaces, one set of drawings and a single audit trail from design intent to as-built record.
Our engineers hold current authorisation for high-voltage working and follow the host network's safety rules on every site — full stop.
Design authority
Single-line diagrams, protection studies and equipment specifications reviewed at independent gates.
Construction supervision
Permit-to-work control, stage inspections and quality hold points with photographic evidence.
Commissioning packs
Test records, settings files and energisation checklists that operators accept first time.
Core services
Five disciplines,
one standard.
Each discipline can be engaged alone or as part of a turnkey package.
01
Substation engineering
AIS and GIS substations from 11 kV up to transmission voltage — civil interface, earthing, protection coordination and SCADA integration, engineered to the host grid code.
02
Overhead line & cable systems
Route surveys, pole and tower design, sag and clearance calculations, and underground cable rating studies — with full easement and permit support.
03
Renewable grid connections
Connection studies, protection settings and switchgear interfaces that take solar, wind and storage assets from application to energisation without grid-code surprises.
04
Maintenance & asset care
Planned maintenance programmes, thermographic surveys, oil testing coordination and condition-based replacement planning that stretch asset life safely.
05
Emergency & fault response
A network desk that triages faults around the clock, dispatches authorised crews and restores supply with a structured post-incident report as standard.
Why Voltline
Built to be the
low-drama option.
Power projects fail in the gaps between disciplines. We close those gaps with written checkpoints, one drawing set and crews that speak the same standard.
A
Single accountability
One contract, one design authority, one audit trail — from feasibility study to the final energisation record.
B
First-time acceptance
Commissioning packs assembled to the host network's own checklist, so witness testing passes on the first visit.
C
Cost certainty
Design freezes at the right gate. Variations need written approval — surprises are engineered out, not billed after.
D
Asset longevity
Condition data captured from day one feeds a replacement plan that stretches asset life without gambling on it.
0Stage gates per project
0/7Fault desk coverage
0%Documented handover
0Independent design reviews
Delivery process
Five gates,
no shortcuts.
Every engagement moves through the same stage gates — with a written checkpoint you must approve before the next phase begins.
01
Scoping
Site visit, load data and a written scope with assumptions listed.
02
Design
Single-line, layouts and protection studies issued for review.
03
Build
Procurement and construction under permit-to-work control.
04
Test
Injection tests, insulation checks and factory witness points.
05
Energise
Switching programme, handover pack and O&M induction.
Sector solutions
Who we power.
Hover a card to flip it — three tailored packages for the sectors that depend on our grid.
Industrial
Hover to flipIndustrial
- Private HV networks & substations
- Power factor & harmonics
- Critical-load protection
- Outage planning
Commercial
Hover to flipCommercial
- LV upgrades & switchboards
- EV charging infrastructure
- Backup power & UPS
- Energy efficiency audits
Utility
Hover to flipUtility
- Network reinforcement design
- Protection scheme upgrades
- Grid-code studies
- Asset condition surveys
Certification & safety
Safety is a
deliverable.
Our management systems are built around internationally recognised frameworks — and our site rules go beyond them.
✓
ISO 9001-aligned quality system
Controlled documents, supplier evaluation and non-conformance tracking on every project.
✓
ISO 45001-aligned safety practice
Permit-to-work, high-voltage isolation and emergency response modelled on international requirements.
✓
ISO 14001-aligned environmental controls
Site-disturbance, waste and containment controls from design through close-out.
✓
Authorised high-voltage working
Duty holders, switching schedules and two-person verification on all live-network activities.
Project cases
Selected engagements.
Anonymised scope summaries — full case packs, including lessons learned, are shared under NDA for pre-qualified clients.
Substation
Primary substation refurbishment
Switchgear replacement and protection upgrade delivered in staged outages, keeping the network live throughout — with zero reportable safety events.
Asset care
Network-wide condition survey
Thermographic and visual surveys across a distribution network, feeding a prioritised, budgeted replacement plan for the client's next three investment cycles.
Before you ask
Answers up front.
The questions every tender team asks us — answered the way we answer them on the first call.
Do you work at transmission voltage?
Yes. We design, supervise and commission work from 11 kV distribution up to transmission voltage. Authorisation levels for each crew are confirmed against your host network's safety rules before mobilisation.
Can you take a turnkey package — or just one discipline?
Both. Most clients start with one discipline — a study, a protection upgrade or a maintenance programme — and extend once the first gate passes cleanly. Turnkey packages run on the same gates, just broader.
How do you handle grid-code compliance?
We treat the host network's code as a design input, not an afterthought: studies and settings are prepared against it, and every asset is tested against it before energisation. Compliance evidence ships in the handover pack.
What does your commissioning pack include?
Test records, protection settings files, as-built drawings, energisation checklists and O&M manuals — assembled to your operator's checklist format, so witness testing passes on the first visit.
Invitation to tender
Put your next
energisation on
our desk.
Send your tender documents or a short brief. Our estimating team responds with questions or a preliminary programme within five working days.
